915nm 70W High Power Diode Lasers With 106.5µm 0.22NA Fiber for pump

915nm 70W High Power Diode Lasers With 106.5µm 0.22NA Fiber for pump

  • 915nm 70W High Power Diode Lasers With 106.5µm 0.22NA Fiber for pump
915nm 70W High Power Diode Lasers With 106.5µm 0.22NA Fiber for pump
Product Details:
Place of Origin: China
Brand Name: BWT
Certification: ISO9001
Model Number: K915FNXRN-70.00W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Delivery Time: 4-8weeks
Payment Terms: T/T
Supply Ability: 100,000/year
Contact Now
Detailed Product Description
Product Name: Laser Diode Module Output Power: 70W
Wavelength: 915nm Fiber Bundle Diameter: 106.5µm
Numerical Aperture: 0.22N.A Application: Laser Pumping Medical Use Material Processing
High Light:

mini laser module

,

high power laser module

Features:

915nm wavelength

70W output power

106.5µm fiber core diameter

0.22N.A.

1040nm-1200nm feedback protection



Applications:

Laser pumping

Medical Use

Material Processing

Specifications(25℃)



Symbol



Unit



K915FNXRN-70.00W
Minimum Typical Maximum
Optical Data CW-Output Power Po W 70 - -
Center Wavelength λc nm 915±10
Spectral Width (FWHM) △λ nm - 6 -
Wavelength Shift with Temperature △λ/△T nm/℃ - 0.3 -
Wavelength Shift with Current △λ/△A nm/A - 1 -
Electrical Data Electrical-to-Optical Efficiency PE %   50 -
Threshold current lth A - 1.1 -
Operating current lop A - 14.5 15.5
Operating voltage Vop V - 9.6 10.5
Slope Efficiency η W/A - 4.8 -

Fiber Data



Core diameter Dcore μm - 106.5 -
Cladding diameter Dclad μm - 125 -
Buffer diameter Dbuf μm - 245 -
Numeric aperture NA - - 0.22 -
Fiber length Lf m - 2 -
Fiber Loose Tubing Diameter - mm 0.9mm PVC 180cm
Minimum Bending Radius - mm 50 - -
Fiber termination - - - None -
Feedback Isolation Back reflection wavelength λ nm 1040-1200
Back reflection isolation - dB - 30 -
Others ESD Vesd V - - 500
Storage temperature Tst -20 - 70
Lead Soldering Temp Tls - - 260
Lead Soldering Time t sec - - 10
Operating case temperature Top 15 - 35
Relative Humidity RH % 15 - 75
