Blue Laser Diode K41S03F-0.03W-S

All Products

blue laser module (3)

green laser module (1)

red diode laser module (27)

diode laser module (25)

808nm diode laser module (33)

915-980nm diode laser module (37)

diode laser driver (1)

diode laser system (4)

v-groove fiber array (4)

fiber coupler (3)

Detailed Product Description

1. Key Features of Blue Laser Diode K41S03F-0.03W-S
30mW output power
3µm fiber core diameter
0.12NA
405nm wavelength

2. Applications of Blue Laser Diode K41S03F-0.03W-S
Printing
Aiming beam

3.Specifications of Blue Laser Diode K41S03F-0.03W-S

Specifications		Symbol	Unit	K41S03F-0.03W-S
Optical data	CW-output power	P_o	mW	30
	Center wavelength	l_c	nm	405
	Tolerance of l	-	nm	±5
	Spectral width (FWHM)	△l	nm	<3
	Temperature drift of l	-	nm/℃	~0.2
Fiber data⁽²⁾	Fiber core diameter	W_c	µm	3
	Numerical aperture	NA	-	0.12
	Fiber connector	-	-	FC, ST, SMA-905
Electrical data	Operation current	I_op	mA	120
	Threshold current	I_th	mA	35
	Slope efficiency	η_D	mW/mA	0.26
	Operation voltage	V_op	V	5±0.5
	Reverse voltage	V_re	V	5
Other specifications	Operation temperature	T_op	℃	10~30
	Storage temperature	T_st	℃	-20~+80
	Expected lifetime	MTBF	h	>5,000
	Dimensions (fiber and connector not included)	-	mm	Φ7.4×34.0
	Lead soldering temperature	T_is	℃	260(10 sec.)

(1) 650nm wavelength is also available,

(2) Other fibers available.
