915nm / 160W Pump Diode Lasers High Power , OEM laser module

915nm / 160W Pump Diode Lasers High Power , OEM laser module

    • 915nm / 160W Pump Diode Lasers High Power , OEM laser module
  • 915nm / 160W Pump Diode Lasers High Power , OEM laser module

    Product Details:

    Place of Origin: China
    Brand Name: BWT
    Certification: ISO9001
    Model Number: K915FN1RN-160.0W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Delivery Time: 4-8weeks
    Payment Terms: T/T
    Supply Ability: 200,000/year
    Contact Now
    Detailed Product Description
    Product Name: High Power Laser Diode Module Output Power: 160W
    Wavelength: 915nm Fiber Bundle Diameter: 106.5µm
    Numerical Aperture: 0.22N.A Application: Fiber Laser Pumping
    High Light:

    high power laser diode

    ,

    medical diode laser

    Features:

    915nm wavelength

    160W output power

    106.5µm fiber core diameter

    0.22N.A.

    1020nm-1200nm feedback protection

    Applications:

    Fiber laser pumping




    Specifications(25℃)



    Symbol



    Unit



    K915FN1RN-160.0W
    Minimum Typical Maximum
    Optical Data CW-Output Power Po W 160 - -
    Center Wavelength λc nm 915±10
    Spectral Width (FWHM) △λ nm - 6 -
    Wavelength Shift with Temperature △λ/△T nm/℃ - 0.3 -
    Wavelength Shift with Current △λ/△A nm/A - 1 -
    Spot ratio 0.15/0.22 NA % - 95 -
    Electrical Data Electrical-to-Optical Efficiency PE %   44 -
    Threshold current lth A - 0.6 -
    Operating current lop A - - 15
    Operating voltage Vop V - - 29
    Slope Efficiency η W/A - 12 -

    Fiber Data



    Core diameter Dcore μm - 106.5 -
    Cladding diameter Dclad μm - 125 -
    Numeric aperture NA NA - 0.22 -
    Fiber length Lf m - 2.0 -
    Fiber Loose Tubing Diameter - μm 0.9mm PTFE
    Minimum Bending Radius - mm 50 - -
    Fiber termination - - - None -
    Feedback Isolation Back reflection wavelength λ nm 1020-1200
    Back reflection isolation - dB - 30 -
    Others ESD Vesd V - - 500
    Storage temperature Tst -20 - 70
    Lead Soldering Temp Tls - - 260
    Lead Soldering Time t sec - - 10
    Operating case temperature Top 15 - 35
    Relative Humidity RH % 15 - 75
