| Place of Origin: | China |
|---|---|
| Brand Name: | BWT |
| Certification: | ISO9001 |
| Model Number: | K976FPACA-300.00W |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Delivery Time: | 4-8weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100,000/year |
| Output Power: | 300W | Wavelength: | 976nm |
|---|---|---|---|
| Fiber Core Diameter: | 400µm | Optical fiber Numerical Aperture: | 0.22NA |
| Applications: | Scientific Research | Name: | 976nm-300W |
| High Light: | scientific research fiber coupled diode laser,fiber coupled diode laser 976nm 300w,fiber coupled 976nm laser diode |
||
976nm-300W
Key Features:
Applications:
|
Specifications(25℃)
|
Symbol
|
Unit
|
K976FPACA-300.00W | ||||
| Minimum | Typical | Maximum | |||||
| Optical Data | CW-Output Power | Po | W | 300 | - | - | |
| Center Wavelength | λc | nm | 976±10 | ||||
| Spectral Width (FWHM) | △λ | nm |
-
|
3 | - | ||
| Wavelength Shift with Temperature | △λ/△T | nm/℃ | - | 0.2 | - | ||
| Electrical Data | Electrical-to-Optical Efficiency | PE | % | - | 50 | - | |
| Threshold current | lth | A | - | 1 | - | ||
| Operating current | lop | A | - | 13.5 | 15 | ||
| Operating voltage | Vop | V | - | 45.5 | 47.5 | ||
| Slope Efficiency | η | W/A | - | 24 | - | ||
|
Fiber Data
|
Core diameter | Dcore | μm | - | 400 | - | |
| Numeric Aperture | NA | - | - | 0.22 | - | ||
| Fiber Length | LmPiuggable output, Fiber length is optional | ||||||
| Fiber Loose Tubing Diameter | - | mm | 3 | ||||
| Fiber termination | SMA905/ Customization | - | |||||
| Aiming beam | Out power | Pa | mW | 2 | |||
| Wavelength | λa | nm | 635±10 | ||||
| Operating voltage | Va | V | - | 2.2 | - | ||
| Operating current | la | mA | - | 45 | 65 | ||
| Others | ESD | Vesd | V | - | - | 500 | |
| Storage temperature | Tst | ℃ | -20 | - | 70 | ||
| Lead Soldering Temp | Tls | ℃ | - | - | 260 | ||
| Lead Soldering Time | t | sec | - | - | 10 | ||
| Operating case temperature | Top | ℃ | 15 | - | 35 | ||
| Relative Humidity | RH | % | 15 | - | 75 | ||
