| MOQ: | 1 Piece/Pieces |
| Delivery Period: | 4-8weeks |
| Payment Method: | T/T |
| Supply Capacity: | 100,000/year |
Features:
976±0.5nm wavelength
60W output power
106.5µm fiber core diameter
0.22N.A.
Applications:
Fiber laser Pump source
| Specifications(25℃) | Symbol | Unit | K976FANCA-60.00W | |||
| Minimum | Typical | Maximum | ||||
|
Optical Data
|
CW-Output Power | Po | W | 60 | - | - |
| Threshold current | Ith | A | - | 0.9 | ||
| Operating current | Iop | A | - | 11 | 13 | |
| Operating voltage | Vop | V | - | -11 | 12 | |
| Slope Efficiency | η | W/A | - | 6 | - | |
| Electrical-to-Optical Efficiency | PE | % | - | 52 | - | |
| Center wavelength | λc | nm | 976±0.5 | |||
| Spectral width(FWHM) | △λ | nm | - | - | 0.7 | |
| Wavelength Shift with Temperature | △λ/△T | nm/℃ | - | 0.02 | - | |
| Wavelength Shift with Current | △λ/△A | nm/A | - | 0.03 | - | |
| Fiber Data | Fliber Length | Lf | m | - | 2 | - |
| Cladding diameter | Dclad | µm | - | 125 | - | |
| Core diameter | Dcore | µm | - | 106.5 | - | |
| Numeric aperture | NA | - | - | 0.22 | - | |
| Fiber Loose Tubing Diameter | - | mm | 0.9 | |||
| Minimum Benfing Radius | - | mm | 50 | - | - | |
| Fiber Termination | - | - | None | |||
| Others | ESD | Vesd | V | - | 500 | |
| Storage Temperature | Tstg | ℃ | -20 | - | 70 | |
| Lead Soldering Temp | Tls | ℃ | - | - | 260 | |
| Lead Soldering Time | t | sec | - | - | 10 | |
| Operating case temperature | Top | ℃ | 20 | - | 30 | |
| Relative Humidity | RH | % | 15 | - | 75 | |
|
Feedback
Isolation
|
Wavelength Range
|
λ | nm | 1020-1200 | ||
| Isolation | - | dB | - | 30 | - | |
|
|
