660nm 2W Fiber Coupled Diode Laser Red Laser
  • name

660nm 2W Fiber Coupled Diode Laser Red Laser

MOQ: 1 Piece/Pieces
Delivery Period: 4-8weeks
Payment Method: T/T
Supply Capacity: 100,000/year
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
BWT
Certification
ISO9001
Model Number
K660DA2FN-2.000WN0N
Product Name:
660nm-2W
Output Power:
2W
Wavelength:
660nm
Fiber Bundle Diameter:
105µm
Numerical Aperture:
0.22NA
Application:
Medical Testing
Highlight:

660nm 2W fiber coupled diode laser

,

Red fiber coupled diode laser

,

Red laser diode to fiber coupling

Product Description

660nm 2W Fiber Coupled Diode Laser



Features:

660nm wavelength

2W output power

105µm/0.22NA



 Applications:

          Medical testing

           Indicator light



The BWT Red Laser has the advantages of small size, high brightness, and high wavelength accuracy. The high-precision wavelength and high brightness spot of red laser achieves high absorption of substances in medical applications, making the detection results more accurate.


Specifications(25℃) Symbol Unit K660DA2FN-2.000WN0N
Minimum Typical Maximum







Optical Data





 CW-Output Power Po W 2 - -
Center Wavelength λc nm 660±3
Wavelength Shift with Temperature △​λ/△T nm/℃ - 0.2 -









   Electrical Data

 Electrocal-to-Optical Efficiency PE % - 25 -
Threshold Curent lth A - 0.5 -
Operating Curent lop A - 2 2.2
Operating Voltage Vop V - 4.2 5
Slioe Efficiency η W/A - 1.3 -





Fiber Data

 Core diameter Dcore µm - 105 -
Numerical Aperture NA - - 0.22 -
Fiber Connector - - FC/PC/SMA905











Others

 ESD Vesd V   - 500
Storage Temperature Tstg ℃ -20 - 70
Lead Soldering Temp Tls ℃ - - 260
Lead Soldering Time t sec - - 10
Operating case temperature Top ℃ 15 - 35
Relative Humidity RH % 15 - 75
