MOQ: | 1 Piece/Pieces |
Delivery Period: | 4-8weeks |
Payment Method: | T/T |
Supply Capacity: | 100,000/year |
Features:
15W output power
200µm fiber bundle diameter
0.22N.A.
976nm wavelength
Applications:
Medical use
Material processing
Specifications(25℃) | Symbol | Unit | K976FANCA-15.00W | |||
Minimum | Typical | Maximum | ||||
Optical Data
|
CW-Output Power | Po | W | 15 | - | - |
Threshold current | Ith | A | - | 1.0 | ||
Operating current | Iop | A | - | - | 11 | |
Operating voltage | Vop | V | - | - | 4 | |
Reverse Voltage | Vre | V | - | 5 | - | |
Slope Efficiency | η | W/A | - | 1.6 | - | |
Electrical-to-Optical Efficiency | PE | % | 40 | - | - | |
Center wavelength | ʎc | nm | 966 | - | 986 | |
Spectral width(FWHM) | δλ | nm | - | 6 | - | |
Wavelength Shift with Temperature | - | nm/℃ | - | 0.3 | - | |
Fiber Data | Buffer diameter | Dbuf | µm | - | 400 | - |
Cladding diameter | Dclad | µm | - | 220 | - | |
Core diameter | Dcore | µm | - | 200 | - | |
Numeric aperture | NA | - | - | 0.22 | - | |
Others | ESD | Vesd | V | - | 500 | |
Storage Temperature | Tstg | ℃ | -20 | - | 70 | |
Lead Soldering Temp | Tls | ℃ | - | - | 260 | |
Lead Soldering Time | t | sec | - | - | 10 | |
Operating case temperature | Top | ℃ | 15 | - | 35 | |
Relative Humidity | RH | % | 15 | - | 75 | |
PD Data | Current | Imo | μA | 200 | - | 2000 |
Thermistor | - | Rt | (K Ω)/β(25℃) | - | 10±3%/3477 | - |
Aiming Beam Data | Output Power | Pa | mW | - | 2 | - |
Wavelength | la | nm | 630 | - | 643 | |
Voltage | Va | V | - | 2.2 | - | |
Current | la | mA | - | 45 | 65 |
