| Place of Origin: | China |
|---|---|
| Brand Name: | BWT |
| Certification: | ISO9001 |
| Model Number: | CTP-16/32/48/64/96/128 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Delivery Time: | 4-8weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100,000/year |
| Fiber Center Interval: | 125µm | Transmissivity: | ＞90% |
|---|---|---|---|
| Product Name: | V-groove Fiber Array | Main Features: | Long-term High Reliability , Good Product Consistency |
| Application: | Scientific Research , CTP | Type: | Diode Laser Accessories |
| High Light: | 125um v groove fiber array,diode laser v groove fiber array,125um diode laser spare parts |
||
Features:
Long-term high reliability
|
Specifications(25℃)
|
Unit
|
CTP-16/32/48/64/96/128 |
| Fiber center Interval | μm | 125 |
| Vertical Precision of Fiber Position | μm | ±4 |
| Transmissivity | - | >909% |
| Fiber Numbers | - | 16/32/48/64/96/128 |
| Fiber core Diameter | μm | 50/60 |
| Fiber Cladding Diameter | μm | 125 |
| Fiber Jacket Diameter | μm | 900 |
| Numerical Aperture | - | 0.14/0.22 |
| Fiber Length | m |
1.0 |
| Fiber Connector | - | FC,ST,SMA-905 |
